25
Publication IASIMP-QS008A-EN-P - March 2009
25
Chapter
3
DataSite and Logix Integration
Introduction
In this chapter, you configure the DataSite unit, download the ControlLogix user program,
configure the ProSoft (MVI56-MNET) Modbus TCP/IP communication module, and connect all
system devices.
Before You Begin
•
Complete your system hardware selection (
).
•
Complete your system layout and wiring (
).
•
Load all DataSite software on your computer as listed in the Preface on page
chapter, you will use the DS FloConfig and RSLogix 5000 software.
•
Assign IP addresses to all devices on network. The table lists IP addresses used in this
quick start.
This chapter assigns IP addresses to the 1756-ENBT Ethernet module, the DataSite unit, and
the Prosoft MV156-MNET module. For details on how to assign an IP address to the
PanelView Plus terminal, refer to the PanelView Plus Terminals User Manual, publication
. For the other devices, refer to the manufacturer’s user manual.
What You Need
•
Personal computer or laptop
•
Hardware:
– 1758-FLOxxx DataSite Unit
– 1756-L63 ControlLogix controller
– 1756-ENBT EtherNet/IP module
Device
IP Address
Device
IP Address
1756-ENBT Ethernet module
192.168.10.90
ProSoft MV156-MNET module
192.168.10.94
Master radio
192.168.10.91
Personal computer
192.168.10.95
Remote radio
192.168.10.92
PanelView Plus 1000 terminal
192.168.10.96
DataSite unit
192.168.10.93
