14
Publication IASIMP-QS008A-EN-P - March 2009
Chapter 1 Hardware Selection
Review Basic Panel Component Listings
The bill of materials (BOM) on the DataSite Accelerator Toolkit CD includes the necessary
components to duplicate the three DataSite configurations covered in this quick start. Review the
component listings and compare with your specific application needs.
Follow these steps to view the BOM on the DataSite Accelerator Toolkit CD for the DataSite to
ControlLogix Master configuration.
1. Launch the DataSite Accelerator Toolkit CD.
2. Select DataSite Development Tools.
3. Choose DataSite to ControlLogix
Master>Bill of Material, then double-click
DataSite_to_CLX.prp.
