4 MP-Series and TL-Series Electric Cylinders Replacement Parts
Rockwell Automation Publication MPAR-IN002B-EN-P - September 2012
TLY-A310F-B-X199
63
10.0 (0.394)
None TLAR-A3xxxE-x2x
TLY-A310F-B-X200 24V Brake TLAR-A3xxxE-x4x
TLY-A310F-B-X201
20.0 (0.787)
None TLAR-A3xxxH-x2x
TLY-A310F-B-X202 24V Brake TLAR-A3xxxH-x4x
Replacement Motor for MPAR-Series Electric Cylinders
Replacement Motor
Cat. No.
Electric Cylinder Attributes
Use with Electric Cylinder
Cat. No.
Voltage Class Frame Size Pitch mm/rev (in./rev) Brake
MPL-A1520F-V-X203
200
32
3.0 (0.118)
None MPAR-A1xxxB-x2x
MPL-A1520F-V-X204 24V Brake MPAR-A1xxxB-x4x
MPL-A1530F-V-X205
10.0 (0.394)
None MPAR-A1xxxE-x2x
MPL-A1530F-V-X206 24V Brake MPAR-A1xxxE-x4x
MPL-A1530F-V-X207
40
5.0 (0.197)
None MPAR-A2xxxC-x2x
MPL-A1530F-V-X208 24V Brake MPAR-A2xxxC-x4x
MPL-A220F-V-X209
12.7 (0.50)
None MPAR-A2xxxF-x2x
MPL-A220F-V-X210 24V Brake MPAR-A2xxxF-x4x
MPL-A330F-M-X211
63
10.0 (0.394)
None MPAR-A3xxxE-x2x
MPL-A330F-M-X212 24V Brake MPAR-A3xxxE-x4x
MPL-A420F-M-X213
20 (0.787)
None MPAR-A3xxxH-x2x
MPL-A420F-M-X214 24V Brake MPAR-A3xxxH-x4x
MPL-B1520F-V-X215
400
32
3.0 (0.118)
None MPAR-B1xxxB-x2x
MPL-B1520F-V-X216 24V Brake MPAR-B1xxxB-x4x
MPL-B1530F-V-X217
10.0 (0.394)
None MPARBA1xxxE-x2x
MPL-B1530F-V-X218 24V Brake MPAR-B1xxxE-x4x
MPL-B1530F-V-X219
40
5.0 (0.197)
None MPAR-B2xxxC-x2x
MPL-B1530F-V-X220 24V Brake MPAR-B2xxxC-x4x
MPL-B220F-V-X221
12.7 (0.50)
None MPAR-B2xxxF-x2x
MPL-B220F-V-X222 24V Brake MPAR-B2xxxF-x4x
MPL-B330F-M-X223
63
10.0 (0.394)
None MPAR-B3xxxE-x2x
MPL-B330F-M-X224 24V Brake MPAR-B3xxxE-x4x
MPL-B420F-M-X225
20.0 (0.787)
None MPAR-B3xxxH-x2x
MPL-B420F-M-X226 24V Brake MPAR-B3xxxH-x4x
Replacement Motors for TLAR-Series Electric Cylinders (continued)
Replacement Motor
Cat. No.
Electric Cylinder Attributes
Use with Electric Cylinder
Cat. No.
Frame Size
Ball Screw Pitch
mm/rev (in./rev)
Brake
