3-2 SP200 AC Drive Remote Keypad
English
View the
number of the
present display
parameter
While in display mode, press and release the
key once. The present display parameter number
will be displayed for 2 seconds. The display will
then return to the present parameter value.
Increment the
display
parameter
number While in display mode, press the key until the
desired parameter is displayed. Following a 2
second delay, the parameter value will be
displayed.
Increment the
program
parameter
number Press the PROG key to enter program mode.
Press the key until the desired number is
displayed.
Decrement the
program
parameter
number Press the PROG key to enter program mode.
Press the key until the desired number is
displayed.
Increment the
current program
parameter value Press the PROG key to enter program mode.
Press the key while the desired program
parameter number is displayed.
Press the key until the desired value is
displayed.
Decrement the
current program
parameter value Press the PROG key to enter program mode.
Press the key while the desired program
parameter number is displayed.
Press the key until the desired value is
displayed.
Clear faults
Press the red key.
Table 3.1 – Keypad Operation (Continued)
Desired Action User Steps
