Operating the Drive Using the Remote Keypad 3-1
English
C
HAPTER
3
Operating the Drive Using
the Remote Keypad
The following table tells you how to operate the keypad.
Table 3.1 – Keypad Operation
Desired Action User Steps
Start the drive 1
Press the green key to start the drive.
Stop the drive
Press the red key to stop the drive.
Jog the drive 1 Press and hold down the JOG key to jog the
drive. The drive will jog at the frequency selected
in P-40 (Internal/Jog Frequency) until the key is
released.
Change the
direction of
rotation Press the key to change the direction of
motor rotation.
Increment the
local speed
reference While in display mode (PROG LED is off), press
the key to increase speed.
Decrement the
local speed
reference While in display mode (PROG LED is off), press
the key to decrease speed.
View the value
of the present
display
parameter While in display mode (PROG LED is off), the
value of the present display parameter is
normally displayed.
1 For the key or JOG key to work, a connection must be present between drive
control terminals 2 and 3. In addition, parameter P-10 must be set to 1.
