About the Remote Keypad 1-3
English
Table 1.2 – Keypad Features
Description
1 The PROGRAM key toggles between display and
program modes. The PROGRAM LED turns on
when the drive is in program mode.
2 In display mode, the ENTER key scrolls through the
display parameters.
In program mode, this key toggles between the
parameter number and parameter value.
3 In display mode, the UP ARROW key increments
the local speed reference.
In program mode, this key increments the parameter
number or parameter value.
4 In display mode, the DOWN ARROW key
decrements the local speed reference.
In program mode, this key decrements the
parameter number or parameter value.
5 The DIRECTION key toggles the drive direction
when keypad control is selected (P-10 = 1) and
reverse is enabled (P-03 = 0).
6 The JOG key issues the jog command to the drive
while pressed when keypad control is selected
(P-10 = 1). 1 The drive will jog at the frequency
selected in P-40 (Internal/Jog Frequency).
1 For drives having software version 3.1 and earlier, the JOG key does not
function. The drive will not respond when the JOG key is pressed.
7 The START key issues start commands to the drive
when keypad control is selected (P-10 = 1).
8 The STOP key issues stop and fault reset
commands to the drive.
9 Display - see section 1.2.
10 Status LEDs - see section 1.3.
