Embedded I/O Expansion Board with 10 Outputs 9
Publication 1799-IN013B-EN-P - May 2013
These tables identifies the signal for the connectors on the 1799-OQ10X.
Connect the Field Output Device to the I/O Connector (P3)
The 1799-OQ10X board has outputs that supply current to your field output
device (sourcing outputs) or sink current from your field output device (sinking
outputs).
Use these wiring diagrams to connect the outputs on this board.
P3 Auxiliary Power
Connector
Pin Signal
1 24V DC
2 24V DC Ret
P2 Output Connector
Pin Signal
1 Output 0
2 Output 1
3 Output 2
4 24V DC Ret
5 Output 3
6 Output 4
7 Output 5
8 Output 6
9 24V DC
10 Output 7
11 Output 8
12 Output 9
