Communicate with Your Module
EtherNet/IP Connection with RSLogix 5000
The following instructions are for RSLogix 5000 version 17 or later.
1. Power down and connect the expansion board to base board.
2. Power up the board and obtain the IP address via DHCP.
3. In the General tab, click the Change button.
4. In the Module Definition screen, select 1799-OQ10X 10 Point 24V
DC output for the expansion module.
5. Click the OK button, then click the Apply button.
1799-OQ10X + 1799-OQ10X Data Definition (optional)
Instance 161 - Consumed 20 Point Output
Consumed
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Out7 Out6 Out5 Out4 Out3 Out2 Out1 Out0
1 Out15 Out14 Out13 Out12 Out11 Out10 Out9 Out8
2 Reserved Out19 Out18 Out17 Out16
3 Reserved
