Outputs, Outputs (sourcing), Outputs (sinking) – Rockwell Automation 1799-OQ10X Embedded I/O Expansion Board with 10 Outputs User Manual
Page 10
10 Embedded I/O Expansion Board with 10 Outputs
Publication
1799-IN013B-EN-P - May 2013
Outputs
Each output can be configured via a dip switch for sinking or sourcing output.
Wire each output in accordance with your selected configuration. Default dip
switch settings are at sinking output. Configure the switches before power-up.
Outputs (Sourcing)
Return
0
1
2 24V dc
24V dc
3
4
5
6
7
8
9
Outputs (Sinking)
Load
Return
0
1
2 24V dc
24V dc
3
4
5
6
7
8
9
Load
45081
OUT
SOURCE
O N
OUT
SINK
10
9
8
7
6
5
4
3
2
1
45073
