FLEX Ex 8 Output and HART Analog Modules 39
Publication 1797-5.3 - September 2011
Thermal Dissipation 20.8 BTU/hr
Module Location Cat. No. 1797-TB3 or 1797-TB3S Terminal Base Unit
Conductors Wire Size 4 mm 2 (12 gauge) stranded max
1.2 mm (3/64 in.) insulation max
Dimensions Metric
Imperial
46 mm x 94 mm x 75 mm
(1.8 in. x 3.7 in. x 2.95 in.)
Weight 200 g (approximately)
Keyswitch Position 4
Environmental Conditions
Operational Temperature -20…+70 ° C (-4…+158 ° F)
Storage Temperature -40…+85 ° C (-40…+185 ° F)
Relative Humidity 5…95% noncondensing
ShockOperating Tested to 15 g peak acceleration, 11(+1) ms pulse width
Nonoperating Tested to 15 g peak acceleration, 11(+1) ms pulse width
Vibration Tested 2 g @ 10…500 Hz per IEC68-2-6
Agency Certification
CENELEC II (1) 2G Ex ib[ia] IIC T4
II (1) D [Ex iaD]
FM Intrinsically safe Class I, Div 1, Groups A, B, C, D, T4.
Associated Apparatus with intrinsically safe
Connection Class I, II, III, Div 1, Groups A--G
Intrinsically safe Class I, Zone 1, AEx ib[ia] IIC T4.
IECEx II (1) 2G Ex ib[ia] IIC T4
II (1) D [Ex iaD]
Certificates
CENELEC DMT 00 ATEX E 042 X
FM FM Certificate Number 3009806
IECEx IECEx BVS 09.0023X
FM
