18 FLEX Ex 8 Output and HART Analog Modules
Publication 1797-5.3 - September 2011
Data Format - Write Words 2 and 3
Data
Format Bits Format Signal Range User Range Resolution
15 14 13 12
11 10 9 8
7 6 5 4 LO HI LO HI
3 2 1 0
0 0 0 0 0 0…20 mA as
Milliamps
0.00 22.00 0
(0.000 mA)
22000
(22.000 mA)
0.1% of
0...20 mA
1 0 0 0 1 0…20 mA as
%
0.00 22.00 0
(0%)
11000
(110.00%)
0.2% of
0...20 mA
2 0 0 1 0 Not assigned
3 0 0 1 1 0…20 mA as
unsigned
integer
0.00 20.00 0
(0.000 mA)
65535
(22.000 mA)
0.03% of
0...20 mA
4 0 1 0 0 4…20 mA as
mA
2.00 22.00 2000
(2.000 mA)
22000
(22.000 mA)
0.01% of
4...20 mA
5 0 1 0 1 Not assigned
6 0 1 1 0
7 0 1 1 1 4…20 mA as
unsigned
integer
4.00 20.00 0
(4 mA)
65535
(20 mA)
0.03% of
4...20 mA
8 1 0 0 0 Not assigned
9 1 0 0 1
10 1 0 1 0
11 1 0 1 1 0...20 mA as
D/A count
0.00 22.00 0
(0 mA)
8000
(22 mA)
0.28% of
0...20 mA
12 1 1 0 0 Not assigned
13 1 1 0 1 4...20 mA as
%
3.00 21.00 -625
(-6.25%)
10625
(106.25%)
0.16% of
4...20 mA
14 1 1 1 0 4...20 mA as
%
2.00 22.00 -1250
(-12.50%)
11250
(112.50%)
0.16% of
4...20 mA
15 1 1 1 1 Not assigned
