15
Publication 2711P-UM003B-EN-P - March 2007
Chapter
2
Configure Unscheduled Communications
Objectives
This chapter shows how to configure a sample ControlNet network
using Unscheduled messaging between a PanelView Plus or
PanelView Plus CE terminal and an Allen-Bradley controller.
Configuring Unscheduled messaging is similar to setting up Ethernet
communications. You do not need to configure settings in the
ControlNet scanner module or use RSNetWorx to configure the
network. Unscheduled communications uses the left over bandwidth
of the ControlNet network to establish its communications.
Software Requirements
Verify that the correct software/firmware is installed on the
development computer and the PanelView Plus or PanelView Plus CE
terminal.
ControlNet Unscheduled Communications
Software/Firmware
PanelView Plus 700-1500
PanelView Plus CE 700-1500
PanelView Plus 400 or 600
RSView Studio
v3.10 or later
v4.0 or later
RSView Machine Edition Runtime
v3.10 or later
v4.0 or later
ControlNet Module Firmware
2711P-RN15S, Series A, Rev A
(firmware v2.07 or later)
(1)
2711P-RN15C, Series A, Rev A
or later
(1)
This applies to terminals that are ordered as pre-configured units with the ControlNet module.
