PanelView Plus and PanelView Plus Compact 400 and 600 Terminals 27

Publication 2711P-IN002G-EN-P - November 2009

Dimensions (HxWxD), approx.

400 keypad, or keypad and touch

152 x 185 x 90 mm (6.0 x 7.28 x 3.54 in.)

600 keypad, or keypad and touch

167 x 266 x 98 mm (6.58 x 10.47 x 3.86 in.)

600 touch

152 x 185 x 98 mm (6.0 x 7.28 x 3.86 in.)

Weight, approx.

400 keypad

(1)

, or keypad and touch

635 g (1.40 lb)

600 keypad, or keypad and touch

(1)

930 g (2.05 lb)

600 touch

(1)

789 g (1.74 lb)

General

Battery life

5 year min at 77 °F (25 °C)

Clock

Battery backup, + /- 2 minutes per month

Status indicators

COMM (Green), Fault (Red)

Application flash memory

20 MB

External compact flash storage

512 MB max

(1)

Add approximately 95 g (0.21 lb) for communication module.

Environmental Specifications

Attribute

Value

Temperature, operating

0…55 °C (32…131 °F)

Temperature, storage

-25…70 °C (-13…158 °F)

Heat dissipation

80 BTU/hr

Altitude, operating

2000 m (6561 ft)

Vibration

10… 57 Hz, 0.012 pk-pk displacement

57…500 Hz 2.0 g pk acceleration

Shock, operating

15 g at 11 ms

Shock, nonoperating

30 g at 11 ms

Relative humidity

5…95% without condensation

Enclosure ratings

NEMA Type 12, 13, 4X (indoor use only), IP54, IP65
