14 10 Input/10 Output Discrete Embedded I/O Boards
Publication 1799-IN003B-EN-P - December 2000
Board Status Indicator (labeled MOD)
Network Status Indicator (labeled NET)
DeviceLogix Status Indicator (labeled DS2)
Auxiliary Power Indicator (labeled AUX PWR)
I/O Status Indicators (labeled Inputs and Outputs)
Indication Status
None No Power
Green
Blinking
Solid Needs commissioning
Device operational
Red
Blinking
Solid Minor fault
Critical fault
Indication Status
None Not On-line
Green
Blinking
Solid On-line/No connections
On-line/Connected
Red
Blinking
Solid Connection timed out
Failed communication: A duplicate
node address exists or module is at
the wrong baud rate.
Indication Status
None Logic disabled
Green
Solid
Blinking Logic enabled
Local forces applied and local logic enabled
Indication Status
None No auxiliary power
Green Auxiliary power present
Indication Status
None Input or output point off
Yellow Input or output point on
