6 MobileView Junction Box
Publication 2727-IN006C-MU-P
Connecting the MobileView Terminal to the Junction Box
Cable Clearance
X1/K3
24V D C
ON LY
TER M IN AL IN
R S422 O U T
ETH ER N ET O U T
+24V
GND
ES1+
ES1-
ES2+
ES2-
ED1+
ED1-
ED2+
ED2-
+24V
GND
ES1+
ES1-
ES2+
ES2-
ED1+
ED1-
ED2+
ED2-
7 8 9
4 5 6
1 2 3
. 0 -
ESC
KE TOP
Ru n Er ro r
10 Base-T
Connection to
Ethernet Network
Safety Equipment
Connections (For
MobileView G750 only)
Typical Control Cabinet
maximum wall
thickness 5 mm (0.2 in)
MobileView Terminal
Junction Box
Connector Cutout
25 ± 0.1 mm
(1.0 ± 0.0039 in)
(0
.94
in)
MobileView
Connection Cable
Dust Cover
X2/K4
Use Grounding
Screw to Connect
Earth Ground to the
Junction Box
Pin 1, 24V dc
Junction Box Cable
Pin 1, 24V dc
S1
S2
S3
K1
MobileView
Terminal Connections
Junction Box Cable
Wire Tie
X1/K3
24
mm
2 m (6.5 ft)
Connection
Cable
K1
Connection Junction Box
Cable
130 mm (5.12 in) 100 mm (3.94 in)
