B-8 Catalog Numbers and Spare Parts Kits
Table A: Spare Parts Kits for Drives with 460V AC Inputs
Level Catalog Number Description Qty in Kit
1 2361-SPE01A Control Fuses, 1250 - 3000A DC units 2 sets
1 2361-SPE12A Line Fuses, 1250A DC units 1 set
1 2361-SPE13A Line Fuses, 1650A DC units 1 set
1 2361-SPE14A Line Fuses, 3000A DC units 1 set
1 2361-SPM01A Feedback Board, 1250 - 3000A DC units 1
1 2361-SPM03A Armature-Pulse Transformer Board, 1250 - 3000A DC units 1
1 2361-SPM04A Field Pulse Transformer Board for Option 14FX, 1250 - 3000A DC units 1
2 2300-SPB01A Line RC Suppressor (Option 14LSP), 1250 - 3000A DC units
1 PCB / 2 sets of
fuses
2 2300-SPJ02A Line MOVs, 1250 - 3000A DC units 1 set
2 2300-SPP01A Air Flow Switch PCB Kit (Option 14AFL), 1250 - 1650A DC units
1 PCB / 1 power
supply (.5A)
2 2300-SPP02A Air Flow Switch PCB Kit (Option 14AFL), 3000A units
1 PCB / 1 power
supply (1.1A)
2 2361-SPA01A Positive (Top) Regenerative Armature Assemblies, 1250A DC units 1
2 2361-SPA02A Negative (Bottom) Regenerative Armature Assemblies, 1250A DC units 1
2 2361-SPA03A Positive (Top) Regenerative Armature Assemblies, 1650A DC units 1
2 2361-SPA04A Negative (Bottom) Regenerative Armature Assemblies, 1650A DC units 1
2 2361-SPA05A Positive (Top) Regenerative Armature Assemblies, 3000A DC units 1
2 2361-SPA06A Negative (Bottom) Regenerative Armature Assemblies, 3000A DC units 1
2 2361-SPA07A Field SCR Module for Option 14FX, 1250 - 3000A DC units 1
2 2361-SPA08A Positive (Top) Non-Regenerative Armature Assemblies, 1250A DC units 1
2 2361-SPA09A Negative (Bottom) Non-Regenerative Armature Assemblies, 1250A DC units 1
2 2361-SPA10A Positive (Top) Non-Regenerative Armature Assemblies, 1650A DC units 1
2 2361-SPA11A Negative (Bottom) Non-Regenerative Armature Assemblies, 1650A DC units 1
2 2361-SPB01A Snubber Assembly, 1250 - 1650A DC units 1
2 2361-SPB02A Snubber Assembly, 3000A DC units 1
2 2361-SPE08A Individual Power Fuses, 1250A DC units 2
2 2361-SPE09A Individual Power Fuses, 1650A DC units 2
2 2361-SPE10A Individual Power Fuses, 3000A DC units 3
2 2361-SPE11A Power Fuse Assembly, 3000A DC units
1 assembly /
3 fuses
2 2361-SPG01A Armature SCRs, 1250A DC units 2
2 2361-SPG02A Armature SCRs, 1650A DC units 2
2 2361-SPG03A Armature SCRs, 3000A DC units 2
2 2361-SPK01A Additional Control Board Stack Power Supply, 1250 - 3000A DC units 1
2 2361-SPM02A Gate Interface Board, 1250 - 3000A DC units 1
3 2361-SPH01A Bridge Fan and Capacitor, 1250 - 1650A DC units 1 each
3 2361-SPH02A Bridge Fan and Capacitor, 3000A DC units 1 each
3 2361-SPH03A Slide-In Fan and Capacitor, 3000A DC units 1 each
