5Ć6
D When a boolean value is combined with an integer value, the
boolean is always treated as the value zero (0) if it is FALSE and
one (1) if it is TRUE.
The following statement illustrates these rules:
A% = SYSTEM DOWN@*(SPEED_REFERENCE - 2.3376)
The value of this statement will be 0 if SYSTEM_DOWN@ is FALSE
or (SPEED_REFERENCE - 2.3376) if SYSTEM_DOWN@ is TRUE.
When a boolean operator is used to combine the two different data
types, it performs a bitĆwise or bitĆforĆbit operation on the two values,
treating the boolean as either an integer one (1) or zero (0):
LOWER_BYTE% = ANALOG_IN% AND OFFH
This operation will mask" off the upper 8 bits of the value
ANALOG_IN%, which can be useful when manipulating integers as
binary data.
5.4 Relational Expressions
It is often necessary in BASIC to compare different values and,
based on the result of that comparison, perform one of several
actions. These comparisons are done with relational operators and
are usually used in conjunction with the IFĆTHEN statement to create
conditional transfers or conditional executions of different parts of a
program. Table 5.4 lists the valid relational or comparison operators
and their meanings.
In forming relational expressions, similar data types must be
compared, i.e., numeric types must be compared to other numeric
types. It would be illegal to compare a boolean or integer
expression to a string expression using a relational operator.
Table 5.4 Ć Relational or Comparison Operators
Operator Example Meaning
= A = B A is equal to B
< A < B A is less than B
> A > B A is greater than B
< = A < = B A is less than or equal to B
> = A > = B A is greater than or equal to B
< > A < > B A is not equal to B
> < A > < B A is not equal to B
