Additional Resources
WARNING:
•
The USB and serial cables are not to exceed 3.0 m (9.84 ft).
•
Do not wire more than 2 conductors on any single terminal.
•
Do not remove the Removable Terminal Block (RTB) until power is removed.
ATTENTION:
•
To comply with the CE Low Voltage Directive (LVD), this equipment must be
powered from a source compliant with the following: Safety Extra Low Voltage
(SELV) or Protected Extra Low Voltage (PELV).
•
To comply with UL restrictions, this equipment must be powered from a Class 2 or
Limited Voltage Limited Current Source (LVLC).
•
For Class I Division 2 applications, use only Class I Division 2 listed or recognized
accessories and modules approved for use within the Micro800 ® platform.
ATTENTION:
•
Electrostatic discharge can damage semiconductor devices inside the module. Do
not touch the connector pins or other sensitive areas.
•
Do not remove the protective debris strips until after the controller and all other
equipment in the panel near the module are mounted and wired. Remove strips
before operating the controller. Failure to remove strips before operating can
cause overheating.
•
Be careful when stripping wires. Wire fragments that fall into the controller could
cause damage. Once wiring is complete, make sure the controller is free of all
metal fragments.
Resource Description
Micro830
®
and Micro850
®
Programmable Controllers
User Manual, publication 2080-UM002
A more detailed description of how to install and use
your Micro830 and Micro850 programmable controllers.
Micro800 AC Power Supply Installation Instructions,
publication 2080-IN001
Information on wiring and installing the optional AC
power supply.
Micro800 Plug-in Modules User Manual,
publication
2080-UM004
Installation, wiring descriptions, and specifications for
the Micro800 plug-in modules.
Micro850 Expansion I/O Modules User Manual,
publication
2080-UM003
Installation, wiring descriptions, and specifications for
the Micro850 expansion I/O modules.
