Micro850 24 Point Programmable Controllers 15
Publication 2080-IN007B-EN-P - April 2014
Isolation
voltage
250V (continuous),
Reinforced
Insulation Type,
Output to Aux and
Network, Inputs to
Outputs.
Type tested for
60 s @ 3250V DC
Output to Aux and
Network, Inputs to
Outputs
150V (continuous),
Reinforced
Insulation Type,
Input to Aux and
Network.
Type tested for
60 s @ 1950V DC
Input to Aux and
Network
250V (continuous),
Reinforced
Insulation Type,
Output to Aux and
Network, Inputs to
Outputs.
Type tested for 60 s
@ 3250V DC
Output to Aux and
Network, Inputs to
Outputs.
50V (continuous),
Reinforced
Insulation Type,
Input to Aux and
Network
Type tested for 60 s
@ 720V DC, Inputs
to Aux and Network
50V (continuous), Reinforced
Insulation Type, I/O to Aux and
Network, Inputs to Outputs.
Type tested for 60 s @ 720 V DC,
I/O to Aux and Network, Inputs to
Outputs.
Pilot duty
rating
C300, R150
–
Insulation
stripping
length
7 mm (0.28 in.)
Enclosure type
rating
Meets IP20
North
American
temp code
T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation
Wiring and Grounding Guidelines, publication
General Specifications
Attribute
2080-LC50
-24AWB
-24QWB
-24QVB
-24QBB
