8 Dataliner DL40 Plus Message Display (Catalog No. 2706-LV2xX, -LV4xX)
Specifications Display Characters
Electrical
Serial Communications
PLC Remote I/O Communications Port (RIO versions only)
Character Height
Two line display
Four line display
11.3 mm (0.44 inch)
11.3 mm (0.44 inch)
Character Set
English
Cyrillic
International
Standard & Extended ASCII Characters
Standard & Cyrillic (Russian) Characters
Standard & International ISO 8859-1 Characters
Characters per Display Line 20
Viewing Distance - Approximate 7.6 meters (25 feet)
Character Type Vacuum fluorescent, 5 x 7 dot matrix characters.
Filtered to blue/green color.
Input Voltage 100 - 240V AC, 50-60 Hz, 0.60 - 0.25A
Input Power 60VA
Fuse Type Internal sealed (not user replaceable)
Annunciation Relay
AC Resistive Load
DC Resistive Load Single N.O. contact
3 Amperes at 240V AC
3 Amperes at 30V DC
Electrical Interface RS-232 (EIA-/TIA-232-E)
RS-485 (EIA-485)
Baud Rate 300, 1200, 9600, 19200
2400, 4800 (2706-LV2S, -LV2R, -LV4S, -LV4R
only)
Data Format 7 or 8 data bits; odd, even, or no parity
Electrical Interface Allen-Bradley Remote I/O Link
Remote I/O Baud Rate 57.6K, 115.2K, or 230.4K
Maximum I/O Cable Distance 10,000 feet (2800m) for 57.6K baud
5,000 feet (1400m) for 115.2k baud
2,500 feet (700m) for 230.4K baud
Rack Sizes 1/4 1/2, 3/4, or 1 (any starting module)
Data Transfer Type Discrete I/O or Block Transfers
