Dataliner DL40 Plus Message Display (Catalog No. 2706-LV2xX, -LV4xX)
Hazardous Location
Installations
Mounting the DL40 Plus
The following pages provide panel cutout dimensions and overall
dimensions for the DL40 Plus displays.
You can also mount the DL40 Plus in a custom panel or enclosure. When a
DL40 Plus is properly installed, the faceplate provides a NEMA Type 12,
13, and 4X(indoor) rating. To install the DL40 Plus:
1. Cut and drill the appropriate mounting holes in the enclosure or panel.
2. Remove the six mounting nuts from the hardware bag provided with the
display.
3. Position the DL40 Plus in the panel or enclosure mounting hole.
4. Install and alternately tighten the nuts to a torque of 10in
•
lbs
(1.13N
•
m).
!
ATTENTION: THIS EQUIPMENT IS SUITABLE
FOR USE IN CLASS I, DIVISION 2, GROUPS A, B,
C AND D, OR NON-HAZARDOUS LOCATIONS
ONLY.
!
ATTENTION: EXPLOSION HAZARD -
SUBSTITUTION OF COMPONENTS MAY IMPAIR
SUITABILITY FOR CLASS 1, DIVISION 2.
!
ATTENTION: EXPLOSION HAZARD - DO NOT
CONNECT OR DISCONNECT EQUIPMENT
UNLESS POWER HAS BEEN SWITCHED OFF OR
THE AREA IS KNOWN TO BE NON-HAZARDOUS.
