Rockwell Automation 2706-LV2xX, -LV4xX Dataliner DL40 Plus Message Display Installation User Manual
Page 4
4
Dataliner DL40 Plus Message Display (Catalog No. 2706-LV2xX, -LV4xX)
Dimensions
2-Line Display
Dimensions
4-Line Display
13.16
(334.2)
3.19
(81.0)
3.16
(80.3)
14.357 (365.0)
4.38
(111.3)
Dimensions are in inches (millimeters)
14.357 (365.0)
6.16
(156.4)
3.19
(81.0)
3.16
(80.3)
13.16
(334.2)
Dimensions are in inches (millimeters)
