Install or Replace the Internal CompactFlash
The logic module is available with or without CompactFlash installed. If ordered separately,
you must install the CompactFlash before attaching the logic module to the display module.
Internal CompactFlash
Follow these steps to replace the internal CompactFlash.
1. Turn the logic module over to expose the circuit board.
2. Unscrew and remove the retaining clip that secures the internal CompactFlash card.
3. Pull out the internal CompactFlash card.
4. Insert the new internal CompactFlash card.
5. Reattach the retaining clip.
Cat. No.
(1)
(1)
The 2711P-RP, 2711P-RPD, and 2711P-RPA logic modules are compatible with any of the internal CompactFlash options.
Description
2711P-RW1
64 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus
logic modules
2711P-RW2
128 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus
logic modules
2711P-RW3
256 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus
logic modules
2711P-RW6
128 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus CE
logic modules
2711P-RW7
256 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus CE logic
modules
2711P-RW8
512 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus CE logic
modules
