Kinetix 6000 Shunt Module 3
Publication 2094-IN004E-EN-P — June 2008
Before You Begin
Remove all packing material, wedges, and braces from within and around the
components. After unpacking, check the item nameplate catalog number against
the purchase order.
Parts List
Install the Kinetix 6000 Shunt Module
These procedures assume you have prepared your panel, mounted your Bulletin
2094 power rail, and understand how to bond your system. For installation
instructions regarding equipment and accessories not included here, refer to the
instructions that came with those products.
Drive Component Ships With
Shunt Module
• Wiring plug for an external shunt resistor (RC).
• Wiring plug for the thermal switch (TS).
•
These installation instructions, publication 2094-IN004.
SHOCK HAZARD
To avoid hazard of electrical shock, perform all mounting and wiring of the
Bulletin 2094 power rail and drive modules prior to applying power. Once
power is applied, connector terminals may have voltage present even when not
in use.
ATTENTION
Plan the installation of your system so that you can perform all cutting, drilling,
tapping, and welding with the system removed from the enclosure. Because
the system is of the open type construction, be careful to keep any metal debris
from falling into it. Metal debris or other foreign matter can become lodged in
the circuitry, which can result in damage to components.
Connector pins on the Bulletin 2094 power rail are covered with a protective
boot. To avoid damage to the power rail during installation, do not remove the
protective boot until you are ready to mount your shunt module.
