18 Dual-Port EtherNet Embedded I/O Board with 10 Inputs/ 10 Outputs
Publication 1799ER-IN001B-EN-P - May 2013
Isolation voltage 50V (continuous), Basic Insulation Type, I/O to Network, and Inputs to
Outputs
No isolation between individual Inputs or Outputs, and Outputs to I/O (Aux)
Power
Type tested at 750V DC for 60 s
Power dissipation 5.8W @ 30V Auxiliary Power In
Ethernet cable type CAT5e shielded or unshielded
Wire size I/O:
0.13...0.5 mm² (26...20 AWG) solid or stranded copper wire rated at 75 oC
(167 °F) or greater. 1.2 mm (3/64 in.) insulation max.
Auxiliary power:
0.80...2.5 mm² (18...14 AWG) solid or stranded copper wire rated at 75 oC
(167 °F) or greater. 1.2 mm (3/64 in.) insulation max.
Ethernet connections:
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum
cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC
24702
Wiring category
(1)
2 - on signal ports
2 - on power ports
2 - on communication ports
(1)
Use this Conductor Category information for planning conductor routing. Refer to publication 1770-4.1 , Industrial
Automation Wiring and Grounding Guidelines.
Environmental Specifications
Attribute Value
Temperature,
operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…70 °C (-4…158 °F)
Temperature,
storage IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Non-operating Thermal Shock):
-40…85 °C (-40…185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% non-condensing
Vibration IEC60068-2-6 (Test Fc, Operating):
2 g @ 10…500 Hz
Shock, operating IEC60068-2-27 (Test Ea, Unpackaged Shock):
30 g
General
Attribute Value
