Communicate with Your Module
Refer to this section only if you are not using RSLogix5000 to communicate with your
I/O board.
This board’s I/O is exchanged through a cyclic, or change-of-state connection.
Cyclic — The block will produce and consume its I/O cyclically at the rate configured.
Change-of-State — Productions occur when an input changes or a fault condition occurs.
If no input or fault condition change occurs within the expected packet rate, a heartbeat
production occurs. This heartbeat production tells the connection originator that the
I/O board is alive and ready to communicate. Consumption occurs when data changes and
the connection originator produces new output data to the I/O block.
Network
status Off The device is not initialized or the module does not have an IP
address.
Flashing green The device has no connections.
The device has an IP address, but no onnections
are established.
Green The device is online, has an IP address, and connections are
established.
Flashing red One or more connections have timed out.
Red The module has detected that its IP address is already in use.
Flashing
red/green The module is performing a powerup self-test.
Module
status Off No power applied to device.
Flashing green Device needs commissioning.
Green Device operating normally.
Flashing red Recoverable fault.
Red Unrecoverable fault – may require device replacement.
Expansion Module connection may be lost. Cycle power to the base
module.
Indicator Status
Status Description
