30 16 Input/16 Output Digital and 2 Input/2 Output Analog Embedded I/O Boards
Publication 1799-IN011A-EN-P - February 2007
Environmental Specifications
Enclosure type rating None (open-style)
Pilot Duty Rating
Pilot duty DC-14
LED indicators Board Status indicator - red/green
Network Status indicator - red/green
DeviceLogix Status indicator - green
Input Point indicator - yellow
Output Point indicator - yellow
Dimensions (H x W x D), approx.
millimeters
(inches)
19.05 x 77.85 x 189.33 mm
(0.75 x 3.07 x 7.45 in.)
Weight 0.10 kg (0.22 lb)
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, Publication 1770-4.1.
Attribute Value
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IIEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...70 °C (-4...158 °F)
Temperature, storage IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40...85 °C (-40...185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5...95% noncondensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Shock, nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Emissions CISPR 11:
Group 1, Class A
ESD immunity IEC 61000-4-2:
6 kV indirect contact discharges
Radiated RF immunity IEC 61000-4-3:
10 V/m with 1 kHz sine-wave 80%AM from 80 MHz...2 GHz
1 V/m with 1 kHz sine-wave 80%AM from 2...2.7 GHz
10 V/m with 200 Hz 50% Pulse 100%AM at 900 MHz
10 V/m with 200 Hz 50% Pulse 100%AM at 1890 MHz
