Rockwell Automation 57C402 25-115V AC/DC Low Power Output Module User Manual
Page 12
3Ć2
AC LINE
TB
1
2
3
4
5
NEON
FU
115 VAC
LIGHT
REED
RELAY
PILOT
LIGHT
PILOT
LIGHT
Figure 3.1 Ć Typical Field Signal Connections
Step 4.
Take the module out of its shipping container. Take it out of
the antiĆstatic bag, being careful not to touch the
connectors on theback of themodule.
Step 5.
Insert themoduleinto thedesired slot in therack. Usea
screwdriver to secure the module into the slot. Refer to
figure3.2.
