Rockwell Automation 2755 High Performance VLD Scanner - Manual (Page 32)

Chapter
4
Installing the Scanner
This chapter provides guidelines and recommendations on how to
install and connect your scanner including;
•
Space Requirements
•
Mounting Scanner
•
Connecting Equipment
•
Installing Package Detector
!
ATTENTION: No user maintenance of the hardware
is required. Do not make adjustments to the scanner
other than those specified in this manual and do not
open the scanner housing. Opening the housing may
damage static sensitive components, and void the
warranty.
!
ATTENTION: If during operation an intense dot of
light is generated instead of a thin line of light, turn the
laser off via the decoder configuration software and
remove power from decoder.
!
ATTENTION: The package detect cap or package
detector must be installed whenever the scanner is in
operation to maintain the NEMA Type 4 seal.
Removing the cap during scanner operation makes the
scanner susceptible to ESD damage.
CAUTION: This laser caution symbol appears
where laser radiation is present.
Chapter Objectives
Warnings and Cautions
