4 Adapter Kit for PanelView 1200/1200e Touch Screen Terminal Cutout
Publication 2711P-IN014D-EN-P - July 2007
Required Tools
These items are required to install the cutout adapter plate.
•
Center punch
•
Scriber
•
Hammer
•
Power jig saw
•
Power drill with 7/32 inch (6 mm) drill bit
•
Socket driver with 3/8 inch socket
•
Torque wrench capable of 1.1 Nm (10 lb-in)
•
Metal file
To install the terminal, you need a slot or Phillips screwdriver.
Disconnect Power to the Terminal
Follow these steps to make sure that the power has been removed to the terminal.
1. Disconnect power at the source and remove the power cord from the
PanelView 1200/1200e terminal.
2. Disconnect all communication cables from the terminal.
Remove the Existing Terminal from the Panel
Follow these steps to remove the terminal from the panel.
1. Remove the mounting clips or nuts and washers that secure the PanelView
1200/1200e terminal to the panel.
2. Slide the terminal out from the panel.
ATTENTION
Make sure that the power cord of the terminal is disconnected, and that all
cables have been disconnected from the rear of the terminal.
