6 POINT I/O™ RTD and Isolated Thermocouple Input Modules
Publication 1734-IN011H-EN-E - February 2014
About the Module
You can use these Series C modules with the following:
•
1734-ACNR ControlNet adapters with RSLogix 5000 software, version 11 or
later
•
1734-ADN, 1734-ADNX, 1734-PDN DeviceNet adapters or with any
1734D POINTBlock I/O module
•
1734-AENT or 1734-AENTR EtherNet/IP adapters with RSLogix 5000
software, version 11 or later
•
1734-APB PROFIBUS adapters
Use this diagram to identify the external features of the module.
POINT I/O Input Module with 1734-TB or 1734-TBS Base
An
alo
g
Vo
lta
ge
Ou
tp
ut
Mo
du
le
Sta
tu
s
Ne
tw
ork
Sta
tu
s
NODE:
0
1
1
10
9
8
7
2
4
5
6
3
The wiring base assembly includes
terminal base, 1734-TB or 1734-TBS,
which consists of a mounting base,
1734-MB, and removable terminal block,
1734-RTB or 1734-RTBS.
46012
