Dependent upon the scanner module being used. For example, the SST Scanner (cat. no. SST-PFB-SLC) does

not fully support Fail Safe mode as it only resets outputs to 0. You cannot define behavior such as Hold Last State
or Fault Value with the SST Scanner.

2

Refer to publication 1770-4.1, Programmable Controller Wiring and Grounding Guidelines.

3

See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates and other

certification details.

PROFIBUS DP Specifications

Network Protocol

PROFIBUS-DP (EN50170)

• Communication of the slave with a Class 1 master

• Communication of the slave with a Class 2 master

Redundancy

Not supported

Repeater Control Signal

RS485 signal

Implementation Type

DPC31

Freeze Mode

Supported

Sync Mode

Supported

Auto Baud Rate

Supported

Fail Safe Mode

Supported

1

Station Type

Slave

FMS Support

Not supported

Indicators

1 red/green module status
1 red/green network status

Number of nodes

100 maximum - rotary switch type node address setting (0-99)

Network Length/
Communication rate

9.6Kbps @ 1000m (3280ft)
19.2Kbps @ 1000m (3280ft)
93.75Kbps @ 1000m (3280ft)
45.45Kbps @ 1000m (3280ft)
187.5Kbps @ 1000m (3280ft)
500Kbps @ 400m (1312ft)
1.5mbps @ 200m (656ft)
3mbps @ 100m (328ft)
6mbps @ 100m (328ft)
12mbps @ 100m (328ft)

Isolation

Type test 1250Vac rms for 60 seconds between field power and
PROFIBUS (I/O to logic)

General Specifications

Wiring Category

2

2

Product Certifications
(when product is
marked)

c-UL-us

UL Listed for Class I, Division 2 Group A,B,C,D Hazardous

Locations, certified for U.S. and Canada

CE

3

European Union 89/336/EEC EMC Directive, compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN61326; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity

C-Tick

3

Australian Radiocommunications Act, compliant with:
AS/NZS CISPR11; Industrial Emissions
