20 DataSite Natural Gas Flow Meter and Remote Terminal Unit
Publication 1758-IN001C-EN-P - June 2011
Status Indicators
Indicator
State
Description
PWR
Green
Power is applied. This indicator is not affected by LED power
control settings.
RUN
Green
Normal operation. This indicator is not affected by LED power
control settings.
STAT
Flashing red
ISaGRAF application running
ERR
Yellow
Error detected
DI0…DI7
Green
Corresponding digital input is on
DO0…DO3
Green
Corresponding digital output is on
PI0…PI2
Green
Corresponding pulse input voltage is more than 8V
TX0
Flashing red
Transmitting data through HART port
RX0
Flashing green
Receiving data through HART port
TX1
Flashing red
Transmitting data through serial port 1
RX1
Flashing green
Receiving data through serial port 1
TX2
Flashing red
Transmitting data through serial port 2
RX2
Flashing green
Receiving data through serial port 2
LINK
Flashing yellow
Transmitting or receiving data through Ethernet port
Yellow
Controller is connected to Ethernet network
10\100M
Red
Speed for ethernet connection, 10\100 Mbps
F\H
Green
Ethernet mode, half duplex or full duplex
PWR STAT DO0 DO2 DI0 DI2
DI4 DI6
PI0 PI2
TX0 TX1 TX2 10\100M
RUN ERR DO1 DO3 DI1 DI3
DI5 DI7
PI1 LINK RX0 RX1 RX2 F\H
