22 ControlNet-to-Foundation Fieldbus H1 Linking Device
Publication 1788-IN051D-EN-P - February 2004
Specifications
Type
Specifications
Operating Temperature
0 to 60°C (32 to 140°F)
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
Storage Temperature
–40 to 85°C (–40 to 185°F)
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal Shock)
Relative Humidity
5 to 95% non-condensing
IEC 60068-2-30 (Test Db, Un-packaged Non-operating Damp Heat)
Vibration
IEC60068-2-6 (Test Fc, Operating): 2g @ 10-500Hz
Physical Dimensions
4.375 in. x 4.375 in x 4.5 in
• ControlNet connectors are on top of the unit
• Allow 1.5 inches for the connectors.
Shock
IEC60068-2-27 (Test Ea, Unpackaged shock):
Operating 30g
Non-operating 50g
Emissions
CISPR 11: Group 1, Class A
ESD Immunity
IEC 61000-4-2:
4kV contact discharges
8kV air discharges
Radiated RF Immunity
IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 1000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
EFT/B Immunity
IEC 61000-4-4: ±2kV at 5kHz on signal ports
Surge Transient Immunity
IEC 61000-4-5: ±1kV line-line(DM) and ±2kV line-earth(CM) on signal ports
Conducted RF Immunity
IEC 61000-4-6: 10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz
Magnetic Field Immunity
IEC 61000-4-8: 30A/m at 50Hz
Enclosure Type Rating
None (open-style)
Communication
• ControlNet - redundant media
• NAP, network access port
• F
OUNDATION
Fieldbus H1, 2 independent channels
• LAS on both channels
• Time Master on both channels
Mounting
35 mm DIN rail
Power Requirements
Class 2 power supply 24V dc
15-30V dc
270 mA @ 24V dc (typical)
