Rockwell Automation 1746-HSCE High-Speed Counter Module Installation Instructions User Manual
Page 7
High-Speed Counter Module 7
Publication 1746-IN011C-EN-P - April 2005
Default settings are shown below:
ATTENTION
Use a small screwdriver to change dip switch positions.
Graphite from pencils will damage the switch.
1
234
N
O
1234
N
O
1
3
SW
2
JW
1
SW
1
JW
1
SW
2
JW
1
SW2 Default
10 to 30V dc
JW1 Default
10 ms filter
SW1 Default
Single-ended
