Rockwell Automation 1771-IFF/A INSTL.INSTR FAST ANALOG INPUT User Manual
Page 19

Publication 1771-IN046B-EN-P - December 2003
Fast Analog Input Module 19
Shock
Operating
Non-operating
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
30g peak acceleration
50g peak acceleration
Vibration
IEC 60068-2-6, (Test Fc, Operating)
2g @ 10-500Hz
ESD Immunity
IEC 61000-4-2:
4kV contact discharges
Radiated RF Immunity
IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 1000MHz
EFT/B Immunity
IEC 61000-4-4:
±1kV at 5kHz on signal ports
Surge Transient Immunity
IEC 61000-4-5:
±2kV line-earth(CM) on shielded ports
Conducted RF Immunity
IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to 30MHz
Emissions
CISPR 11
Group 1, Class A (with appropriate enclosure)
Enclosure Type Rating
None (open-style)
Field Wiring Arm
Cat. No. 1771-WG
Field Wiring Arm Screw Torque
9 pound-inches (1.0Nm)
Conductors Wire Size
Category
14 AWG (2.5mm
2
) - 22 AWG (0.25mm
2
) solid or stranded copper
wire rated at 75°C or greater
3/64 inch (1.2mm) insulation maximum
2
1
Keying
between 10 and 12
between 24 and 26
Certifications (when product is
marked)
UL - UL Listed Industrial Control Equipment
CSA - CSA Certified Process Control Equipment
CSA - CSA Certified Process Control Equipment for Class I,
Division 2, Groups A, B, C and D Hazardous locations
CE
2
-
European Union 89/336/EEC EMC Directive,
compliant with:
EN 50082-2; Industrial Immunity
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61326; Meas./Control/Lab., Industrial Requirements
C-Tick
2
- Australian Radiocommunications Act compliant with
AS/NZS CISPR 11, Industrial Emissions
User Manual
Publication 1771-6.5.116
1
Use this conductor category information for planning conductor routing as described in publication
1770-4.1, “Industrial Automation Wiring and Grounding Guidelines.”
2
See the Product Certification link at
www.ab.com
for Declaration of Conformity, Certificates, and
other certification details.
Description
Value
