High Resolution Thermocouple/Millivolt Input Module 2
Publication 1771-5.66 – October 1998
This product has the CE mark and is approved for installation within
the European Union and EEA regions. It has been designed and
tested to meet the following directives.
EMC Directive
This product is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) and the following standards,
in whole or in part, documented in a technical construction file:
•
EN 50081-2EMC – Generic Emission Standard,
Part 2 – Industrial Environment
•
EN 50082-2EMC – Generic Immunity Standard,
Part 2 – Industrial Environment
This product is intended for use in an industrial environment.
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC
Low Voltage, by applying the safety requirements of EN 61131–2
Programmable Controllers, Part 2 – Equipment Requirements and
Tests.
For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as these Allen-Bradley
publications:
•
Industrial Automation Wiring and Grounding Guidelines For
Noise Immunity, publication 1770-4.1
•
Guidelines for Handling Lithium Batteries, publication AG-5.4
•
Automation Systems Catalog, publication B111
This equipment is classified as open equipment and must be mounted
in an enclosure during operation to provide safety protection.
The 1771-IXHR/C module can be used with any 1771 I/O chassis.
Compatibility and data table use is listed below.
atalo
Use of Data Table Compatibility
Catalog
Number
Input
a e
Output
a e
Read
Bloc Write
Bloc
Addressing
Chassis
erie
Nu ber
Bits
Bits
Block
Words
Block
Words 1/2-Slot 1-Slot 2-Slot
a i
Series
1771-IXHR/C 8 8 12/13 27/28 Yes Yes Yes A, B
A = Compatible with 1771-A1, -A2, -A4 chassis
B = Compatible with 1771-A1B, -A2B, -A3B, -A4B chassis
Yes = Compatible without restriction
No = Restricted to complementary module placement
Do not use this module with Cat. No. 1771-AL adapter, PLC-2/20 or
2/30 programmable controllers.
Understand Compliance to
European Union Directives
Understand Product
Compatibility
