High Resolution Thermocouple/Millivolt Input Module 12
Publication 1771-5.66 – October 1998
Value Description
Conductors Wiring
Category
Use Belden 8761 shielded twisted pair for mV
Use thermocouple manufacturer recommended shielded
thermocouple wire for all thermocouple inputs.
2
Field Wiring Arm Cat. No. 1771-WI
Wiring Arm Screw Torque 7-9 inch-pounds
Agency Certification
(when product is marked)
•
CSA certified
•
CSA Class I, Division 2, Groups A, B, C, D certified
•
UL listed
•
CE marked for all applicable directives
User Manual Publication 1771-6.5.80
Refer to publication 1770-4.1, Industrial Automation Wiring and Grounding Guidelines for Noise Immunity.
The Series B and C versions of the High Resolution
Thermocouple/Millivolt module have CE certification. In all other
respects, the modules are equal.
