ArmorBlock MaXum 2 Input Module Series B 11
Publication 1792D-IN019B-EN-P - September 2000
Specifications
2 Input Module - Cat. No. 1792D-2BV0D
Input Specifications Max Min
Inputs per block 2 - 3 wire or dry contact PNP or NPN devices
Sensor Source Current (per input) 100mA -
Off-Wire Sense Current 0.5mA -
General Specifications
Indicators Net/Mod Status - red/green
Point LED - yellow/orange/red
Logic Status - red/green
Communication Rate
•25Kbps @ 500 meters(1600 feet) for thick cable,
flat media length 375 meters (1230 feet)
•250Kbps @ 200 meters(600 feet) for thick cable,
flat media length 150 meters (492 feet)
•500Kbps @ 100 meters (330 feet) for thick cable,
flat media length 75 meters (246 feet)
DeviceNet Power Voltage
Current
Refer to the graphs in the
Overview section of the
ArmorBlock I/O Family Technical
Data, pub. no.
1792-TD001B-EN-P.
25V dc max
150mA max (no sensors) 11V dc min
up to.8A (2 sensors @
100mA per sensor)
Dimensions (assembled to base)
inches - (millimeters) 1.9H x 2.7w x 4.72D
(48.26)H x (68.6)W x (120)D
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock Operating
Non-operating
Vibration
-25 to 60
o
(-13 to 140
o
F)
-25 to 80
o
C (-13 to 176
O
F)
5 to 100%
30g peak acceleration, 11 (+1) ms pulse width
50g peak acceleration, 11(+1)ms pulse width
Tested 10g @ 10-500Hz per IEC 68-2-6
Conductors Publication DN-6.7.2
Enclosure Meets or exceeds IP67
Agency Certification
(when product is marked)
• CSA certified
• CSA Class 1, Division 2, Groups A, B, C, D
certified
• UL listed
• CE marked for all applicable directives
Technical Data (user information) Publication 1792-TD001B-EN-P
