9 ArmorBlock-LP 16 Input Module
Publication 1792-5.6 – September 1997
Specifications
16 Input Module – Cat. No. 1792-IB16LP
Input Specifications
Inputs per Block 16 sinking
On-state Voltage Range 12–30V dc
On-state Current Maximum
Minimum 15.0mA @ 30V dc
1.6mA @ 12V dc
Off-state Voltage Maximum 5V dc
Off-state Current Minimum 0.8mA
Transition Voltage 5–12.0V dc
Transition Current 0.8–2.2mA
Input Signal Delay
Off to On or On to Off 1ms maximum
Sensor Source Voltage
Current
Minimum 13V dc @ 800mA out and
DeviceNet power = 15V dc
50mA per point, 0.8A total per module
Indicators Network Status – red/green
Module Status – red/green
Sensor Power Supply Status – green
Module Power Supply Status – green
Short Circuit Sensors – red
I/O Status – yellow
Communication Rate in Baud 125k, 250k, 500k selectable
General Specifications
DeviceNet Power Voltage
Current 11.0 – 25.0V dc
100mA (no powered sensors)
900mA (full sensor load)
Dimensions Inches
Millimeters 6.0H X 2.4W X 2.0D
152H X 60W X 51D
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock
Operating
Non-operating
Vibration
0 to 60 o C (32 to 140 o F)
–20 to 80 o C (–40 to 176 o F)
up to 100%
30 g peak acceleration, 11(+1)ms pulse width
50 g peak acceleration, 11(+1)ms pulse width
Tested 10 g @ 10–500Hz per IEC 68-2-6
Specifications continued on next page.
