Page 3
Installation Instructions
MicroLogix 1200 Programmable Controllers
(Cat. No. 1762-L24AWA, 1762-L24BWA, 1762-L24BXB, 1762-L40AWA,
1762-L40BWA, 1762-L40BXB, 1762-L24AWAR, 1762-L24BWAR,
1762-L24BXBR, 1762-L40AWAR, 1762-L40BWAR, 1762-L40BXBR)
Inside . . .
Important User Information ................................................................................. 4
For More Information ........................................................................................... 5
Overview .............................................................................................................. 6
Controller Description .......................................................................................... 7
Hazardous Location Considerations .................................................................... 8
Mounting the Controller .................................................................................... 10
Connecting 1762 I/O Expansion Modules ......................................................... 14
Wiring the Controller ......................................................................................... 15
Specifications .................................................................................................... 21
