Output Specifications
General
Relay Contact Ratings
Description 1762
-L24AWA
-L24BWA
-L24AWAR
-L24BWAR -L24BXB
-L24BXBR -L40AWA
-L40BWA
-L40AWAR
-L40BWAR -L40BXB
-L40BXBR
Relay and FET Outputs
Maximum Controlled Load 1440 VA
Maximum Continuous Current:
Current per Group Common 8A 7.5A 8A 8A
Current per Controller at 150V max 30A or total of per-point loads, whichever is less
at 240V max 20A or total of per-point loads, whichever is less
Relay Outputs
Turn On Time/Turn Off Time
10 msec (minimum) (1)
(1) scan time dependent
Load Current 10 mA (minimum)
Maximum Volts Amperes Amperes
Continuous Volt-Amperes
Make Break Make Break
240V ac 7.5A 0.75A 2.5A (2)
(2) 1.5A above 40°C.
1800 VA 180 VA
120V ac 15A 1.5A 2.5A (2) 1800 VA 180 VA
125V dc
0.22A
(1)
(1) For dc voltage applications, the make/break ampere rating for relay contacts can be determined by dividing 28 VA by the
applied dc voltage. For example, 28 VA/48V dc = 0.58A. For dc voltage applications less than 14V, the make/break ratings
for relay contacts cannot exceed 2A.
1.0A
28 VA
24V dc 1.2A (1) 2.0A
