Rockwell Automation 1771-IFF/A,D17716.5.116 FAST ANALOG INPUT MODULE - Manual (Page 71)

A-3
Publication 1771Ć6.5.116 - July 1996
Table A.C
Scan Time/SingleĆEnded Mode/Disabled Channels
Block Transfer Write Word 41 Oversample = 1x Default Oversample
Channels Disabled Channels Enabled Word 24 Time (ms) Word 24 Time (ms)
0 16 798 7.98 392 3.92
1 15 749 7.49 369 3.69
2 14 700 7.00 345 3.45
3 13 652 6.52 322 3.22
4 12 602 6.02 298 2.98
5 11 554 5.54 274 2.74
6 10 504 5.04 250 2.50
7 9 455 4.55 227 2.27
8 8 406 4.06 203 2.03
9 7 357 3.57 179 1.79
10 6 308 3.08 155 1.55
11 5 259 2.59 132 1.32
12 4 210 2.10 108 1.08
13 3 161 1.61 84 0.84
14 2 112 1.12 60 0.60
15 1 63 0.63 37 0.37
Table A.D
Scan Time/SingleĆEnded Mode/Disabled Channels
Block Transfer Write Word 41 Oversample = 1x Default Oversample
Channels Disabled Channels Enabled Word 24 Time (ms) Word 24 Time (ms)
0 8 402 4.02 199 1.99
1 7 353 3.53 176 1.76
2 6 304 3.04 152 1.52
3 5 255 2.55 129 1.29
4 4 206 2.06 104 1.04
5 3 157 1.57 81 0.81
6 2 108 1.08 57 0.57
7 1 58 0.58 33 0.33
