12 ArmorBlock 16-Point EtherNet/IP Module, Series A
Publication
1732E-IN002B-EN-E - February 2011
•
If an I/O point is to be an input, wire the input device as normal and
leave the associated output de-energized at all times.
I/O Self-configure Circuitry
Refer to the illustration for configuration operations.
Configure Operations
Output scan list
Turn output on
Output
circuit
Sensor or
actuator
Connector pin
Input is on
(or output is on)
Input
circuit
43601
Input scan list
From PLC
To PLC
EtherNet/IP D-Code
M12 connector
Network address
switches
Auxiliary power
44231
M12 I/O
connectors
M12 I/O
connectors
