Indicator Status for Modules
Status
Description
Recommended Action
Module status
Off
No power applied to device.
Apply power to device.
Green
Device operating normally.
None.
Flashing green
Device needs commissioning
due to missing, incomplete, or
incorrect configuration.
Configure device properly.
Flashing red
Recoverable fault.
1. Cycle power to device.
2. If condition persists, replace
device.
Red
Unrecoverable fault – may
require device replacement.
Replace device.
Flashing red/green Device is in self-test mode.
None.
Network status Off
Device is not online:
- Device has not completed
dup_MAC-id test.
- Device not powered – check
module status indicator.
Apply power to device, wait for
MAC_id to complete and correct
as needed.
Flashing green
Device is online but has no
connections in the established
state.
None – device is in Idle or
Program mode.
Green
Device is online and has
connections in the established
state.
None.
Flashing red
One or more I/O connections are
in timed-out state.
Check for I/O module failure and
correct as needed.
Red
Critical link failure – failed
communication device. Device
detected error that prevents it
from communicating on the
network.
Verify that adapter and terminal
bases are properly installed and
reinstall as needed.
Flashing red/green Communication faulted device –
the device has detected a
network access error and is in
communication faulted state.
Device has received and
accepted an Identity
Communication Faulted Request
– long protocol message.
Verify that adapter is properly
installed and reinstall as
needed.
I/O status
Off
All outputs inactive.
None.
Yellow
One or more outputs are active
and under control.
None.
