Compact High-density Analog Current Input Module 21
Publication 1769-IN085A-EN-P - August 2008
The bits are defined as follows:
•
SGN = Sign bit in 2’s complement format
•
Real Time Sample Value = Provides the ability to configure the Real Time
Sample Rate
•
ETS = Enable Time Stamping
•
EC = Enable Channel
•
EA = Enable Alarm
•
AL = Alarm Latch
•
EI = Enable Input Process Alarm Interrupt
(1)
•
Input Filter Sel Ch x = Input Channel Filter Setting
•
Input Data Format Ch x = Input Data Format Select
•
Input Type/Range Select Ch x = Input Type/Range Select
•
Process Alarm High Data Value Channel x = Provides the ability to configure
the Input Process Alarm High Value
•
Process Alarm Low Data Value Channel x = Provides the ability to configure
the Input Process Alarm Low Value
•
Alarm Dead Band Value Channel x = Provides the ability to configure the
Dead Band Value
Word 86 EC Reserved EA AL EI (1) Reserved Input Filter Sel Ch14
Word 87 Reserved Input Data
Format Ch14 Reserved Input Type/Range
Select Ch14
Word 88 SGN Process Alarm High Data Value Channel 14
Word 89 SGN Process Alarm Low Data Value Channel 14
Word 90 SGN Alarm Dead Band Value Channel 14
Word 91 Reserved
Word 92 EC Reserved EA AL EI (1) Reserved Input Filter Sel Ch15
Word 93 Reserved Input Data
Format Ch15 Reserved Input Type/Range
Select Ch15
Word 94 SGN Process Alarm High Data Value Channel 15
Word 95 SGN Process Alarm Low Data Value Channel 15
Word 96 SGN Alarm Dead Band Value Channel 15
Word 97 Reserved
(1) Alarm interrupts are not supported by all bus masters. Check your controller’s user manual to determine if expansion I/O
interrupts are supported.
Configuration Data Array
Word/Bit 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
