Rockwell Automation 1769-IF16C Conpact High Density Analog Current Input Module User Manual
Page 18
18 Compact High-density Analog Current Input Module
Publication 1769-IN085A-EN-P - August 2008
Word 14
EC
Reserved
EA
AL
Reserved
Input Filter Sel Ch2
Word 15
Reserved
Input Data
Format Ch2
Reserved
Input Type/Range
Select Ch2
Word 16
SGN
Process Alarm High Data Value Channel 2
Word 17
SGN
Process Alarm Low Data Value Channel 2
Word 18
SGN
Alarm Dead Band Value Channel 2
Word 19
Reserved
Word 20
EC
Reserved
EA
AL
Reserved
Input Filter Sel Ch3
Word 21
Reserved
Input Data
Format Ch3
Reserved
Input Type/Range
Select Ch3
Word 22
SGN
Process Alarm High Data Value Channel 3
Word 23
SGN
Process Alarm Low Data Value Channel 3
Word 24
SGN
Alarm Dead Band Value Channel 3
Word 25
Reserved
Word 26
EC
Reserved
EA
AL
Reserved
Input Filter Sel Ch4
Word 27
Reserved
Input Data
Format Ch4
Reserved
Input Type/Range
Select Ch4
Word 28
SGN
Process Alarm High Data Value Channel 4
Word 29
SGN
Process Alarm Low Data Value Channel 4
Word 30
SGN
Alarm Dead Band Value Channel 4
Word 31
Reserved
Word 32
EC
Reserved
EA
AL
Reserved
Input Filter Sel Ch5
Word 33
Reserved
Input Data
Format Ch5
Reserved
Input Type/Range
Select Ch5
Word 34
SGN
Process Alarm High Data Value Channel 5
Word 35
SGN
Process Alarm Low Data Value Channel 5
Word 36
SGN
Alarm Dead Band Value Channel 5
Word 37
Reserved
Configuration Data Array
Word/Bit
15
14
13
12
11
10
09
08
07
06
05
04
03
02
01
00
