Publication 1764-UM001B-EN-P - April 2002
A-6 Specifications
Surge Current
per Point peak current 4.0A Not Applicable
maximum surge
duration 10 msec Not Applicable
maximum rate of
repetition at 30°C
(86°F) once every second Not Applicable
maximum rate of
repetition at 55°C
(131°F) once every 2
seconds Not Applicable
Current per
Common maximum total 6A Not Applicable
On-State
Current minimum 2.5 mA at 14V dc 2.0 mA at 10V dc
Off-State
Leakage
Current maximum 1 mA 1 mA
Turn-On Time maximum 0.1 msec 6 µsec
Turn-Off Time maximum 1.0 msec 18 µsec
Repeatability maximum n/a 2 µsec
Drift maximum n/a 1 µsec per 5°C
(1 µsec per 9°F)
(1) Outputs 2 and 3 are designed to provide increased functionality over the other FET outputs (4 through 7). They
may be used like the other FET transistor outputs, but in addition, within a limited current range, they may be
operated at a higher speed. Outputs 2 and 3 also provide a pulse train output (PTO) or pulse width modulation
output (PWM) function.
Table A.7 1764-28BXB FET Output Specifications
Specification General
Operation
(Outputs 2 thru 7) High Speed
Operation
(1)
(Outputs 2 and 3 Only)
