1 Publication 1790-UM001A-EN-P - March 2002
Appendix
A
Specifications
DeviceNet Analog Base Terminal Block
The following table contains specifications that are common to all of
the blocks in this document. Individual base block specifications are
detailed after this table.
Environmental Specifications
Operating
Temperature 0 to 55°C (32 to 131°F)
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
Storage Temperature -40 to 85°C (-40 to 185°F)
IEC 60068-2-1 (Test Ab, Un-packaged Non-operating Cold),
IEC 60068-2-2 (Test Bb, Un-packaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Un-packaged Non-operating Thermal
Shock)
Relative Humidity 5-90% non-condensing
IEC 60068-2-30 (Test Db, Un-packaged Non-operating)
Operating Altitude 2000m
Vibration IEC60068-2-6 (Test Fc, Operating):
2g @ 10-500Hz
Shock
Operating
Non-operating
IEC60068-2-27 (Test Ea, Unpackaged Shock):
10g
30g
Emissions CISPR 11:
Group 1, Class A
ESD Immunity IEC 61000-4-2:
8kV air discharges
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 80MHz to 1000MHz
10V/m with 200Hz 50% Pulse 100%AM @ 900Mhz
EFT/B Immunity IEC 61000-4-4:
+1kV @ 5kHz on power ports
+2kV @ 5kHz on signal ports
+2kV @ 5kHz on communications ports
Surge Transient
Immunity IEC 61000-4-5:
+1kV line-line(DM) and +2kV line-earth(CM) on power ports
+1kV line-line(DM) and +2kV line-earth(CM) on signal ports
+2kV line-earth(CM) on shielded ports
Conducted RF
Immunity IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHzto 80MHz
