Publication 1790-UM001A-EN-P - March 2002
1-2 Overview
General Description The analog input module converts and digitally stores analog data for
retrieval by controllers, such as the SLC-500 programmable controller.
The module supports connections from any combination of up to four
voltage or current analog sensors. The four high-impedance input
channels can be wired as single-ended inputs.
The output module provides two single-ended analog output
channels, either voltage or current, depending on the module
selected.
Table 1.1 lists the CompactBlock LDX module types and
corresponding operating ranges:
Each analog base module supports up to two CompactBlock LDX
discrete expansion modules.
Table 1.1
CompactBlock LDX Module Types and Operating Ranges
CompactBlock LDX
Module
Type: Operating Range:
1790D-N4CO
1790D-TN4CO
Current Input 4-20mA
or
0-20mA
1790D-NOC2
1790D-TNOC2
Current Output 0-20mA
1790D-N4VO
1790D-TN4VO
Voltage Input 0-10V dc
1790D-NOV2
1790D-TNOV2
Voltage Output 0-10V dc
